2016 IndyCar Indy 500 Official Frequencies for CHIRP, Baofeng Radios
May23

2016 IndyCar Indy 500 Official Frequencies for CHIRP, Baofeng Radios

If you’ve wanted to listen in to team radio and track announcements- now you can do it yourself for about the same price as rental! Plus you’ll be able to do it every year afterwards at no extra cost.

>>> Download Chirp CSV Frequencies file <<<

2015_StartV1_1600x800Cars are input on channels that correspond with their number. So if you see a car pulling into the pits, or watching the lead change- perhaps a crash just happened- you should be able to type in the car number into your radio to skip directly to that frequency.  All car and track frequencies are set with “Duplex off” to avoid accidentally transmitting on these frequencies.

I use CHIRP to program my Baofeng radio, and then export it to a CSV file that anyone else can use to import, or use as reference for a different programming method. You are free to use it and share with your family and friends. All driver frequencies are taken from the official spotters guide. Additionally, I have added in frequencies that in the past have included the PA system, race officials, broadcast radio feed, and TV feeds. Some of these might not work- but they are there to experiment with. (Channels 116-127)

Finally- my export includes local Indianapolis repeaters and national calling frequencies for HAM operators. You must hold a Armature Radio License in order to transmit on these frequencies- but you can always listen! (Channels 100-115) (Learn more about obtaining your HAM license here)

GEAR—

Don’t have the gear to listen this year? It’s not too late. Amazon has everything you need- and if you’re in Indy- you can get free SAME DAY delivery if you’re a Prime member.

Radio:

Baofeng Black UV-5R V2+ Plus (Same day Prime eligible)
Baofeng UV-5R Dual Band (cheapest entry price)
Baofeng UV-82 (the radio I use)

Headphones

Powerstroke PSL4HPK Noise Suppression/Voice Amplifying Headphones (headphone I use)
Howard Leight 1030110 Sync Noise-Blocking Stereo Earmuff (Same day Prime eligible)
Howard Leight by Honeywell 1010390 Hi-Vis Radio and MP3 Ear Muff (built in radio)
3M TEKK WorkTunes Hearing Protector, MP3 Compatible with AM/FM Tuner

Earbuds – use your own, along with standard ear muff protection

3M Peltor H10A Optime 105 Earmuff (hearing protection only- use your own earbuds)

PROGRAMMING—

Download Chirp here: http://chirp.danplanet.com/projects/chirp/wiki/Download
Learn how to install Chirp and necessary drivers here: http://www.miklor.com/COM/UV_CHIRP.php

The Miklor site is the best out there for Baofeng info! http://www.miklor.com/

(Other Chirp compatible radios)
If you already own or want to buy something other than the Baofengs listed above- the Chirp software should be able to program any of the following radios.

AnyTone

  • AT-5888UV
    Also includes the Intek HR-2040
    Also includes the Polmar DB-50M
    Also includes the Powerwerx DB-750

Alinco

  • DR-03T
  • DR-06T
  • DR135T
  • DR235T
  • DR435T
  • DJ596T
  • DJ175T

Baofeng/Pofung

  • F-11
  • UV-3R
  • UV-5R and variants
  • UV-6
  • UV-82/82L/82X
    Also includes the GT-5
  • UV-82C
  • UV-82HP/82DX/82HX
  • UV-B5/B6
    Also includes the BF-V85
  • BF-666S/777S/888S
    Also includes the GT-1
  • BF-F8HP
    Also includes the BF-A58
    Also includes the BF-F9V2+
    Also includes the GT-3TP
    Also includes the UV-5RTP
    Also includes the UV-5R7W

Baojie

  • BJ-UV55
  • BJ-9900

BTECH

  • UV-2501
  • UV-2501+220
  • UV-5001

Feidaxin

  • FD-150A
  • FD-160A
  • FD-268A
  • FD-268B
  • FD-288A
  • FD-288B
  • FD-450A
  • FD-460A

Icom

  • IC-80AD
  • IC-2820H
  • ID-800H
  • ID-880H
  • IC-208H
  • IC-2200H
  • IC-91/92AD
  • IC-V/U82
  • ID-RPx000V/RP2x
  • IC-2100H
  • IC-2720H
  • IC-T70
  • IC-T7H
  • IC-T8A
  • IC-Q7A
  • IC-W32A
  • IC-746
  • IC-7200
  • IC-7000
  • ID-31A
  • ID-51A

Intek

  • KT-980HP

Jetstream

  • JT220M
  • JT270M
  • JT2705M (use QYT KT-UV980)
Juentai

  • JT-6188 Mini (use QYT KT8900)

Kenwood

  • TH-D7A/G
  • TH-D72
  • TH-F6A
  • TH-F7E
  • TH-G71A
  • TH-K2
  • TK-260/270/272/278
  • TK-260G/270G/272G/278G
  • TK-360/370/372/378
  • TK-760/762/768
  • TK-760G/762G/768G
  • TK-860/862/868
  • TK-860G/862G/868G
  • TK-7102/8102/7108/8108
  • TM-271A
  • TM-281A
  • TM-D700
  • TM-D710
  • TM-G707
  • TM-V7A
  • TM-V71A

KYD

  • NC-630A

Leixen

  • VV-898

Puxing

  • PX-2R (UHF)
  • PX-777

QYT

  • KT-UV980
  • KT8900 (same as KT-8900)

Retevis

  • H-777 (use Baofeng BF-888)
  • RT-B6 (use Baofeng UV-B5)

Sainsonic

  • GT-890 (use QYT KT8900)

TYT

  • TH-UV3R
  • TH-UVF1
  • TH-9000
  • TH-9800

Yaesu

  • FT-1D
  • FT-50R
  • FT-60R
  • FT-90R
  • FT-817/ND
  • FT-857/D
  • FT-897
  • FT-1802M
  • FT-2800M
  • FT-1900R/2900M
  • FT-7800R/7900R
  • FT-8800R
  • FT-8900R
  • FTM-350R
  • VX-170
  • VX-2R
  • VX-3R
  • VX-5R
  • VX-6R
  • VX-7R
  • VX-8R

WACCOM

  • MINI-8900

Wouxun

  • KG-UVD1P/UV2D/UV3D
  • KG-UV6D/UV6X
  • KG-UV8D
Read More
2016 IndyCar Scanning Frequencies for Chirp
May12

2016 IndyCar Scanning Frequencies for Chirp

Looking for the 2016 Indy 500 frequencies? — Go to 2016 IndyCar Indy 500 Official Frequencies for CHIRP, Baofeng Radios



The following file can be used to import the scanning Indianapolis_RCfrequencies to your handheld HAM radio using the Chirp software. According to the Chirp website, you should be able to program any of the radios listed below.  I have the cars frequencies lined up on the channel that corresponds with their car number.  Channels 122 and up are (from last year) frequencies used by race officials, the PA system, and the IMS broadcast.  These, along with channels 100-114 (local repeaters and national calling Freqs) have been set to skip by default- so you don’t stumble on them during a race.

—> CSV Export file <—

I will update this list again before the One Hundredth Running of the Indianapolis 500.
***All frequencies were found via the offical spotters guide from IndyCar.com.***

Download Chirp here: http://chirp.danplanet.com/projects/chirp/wiki/Download
Learn how to install Chirp and necessary drivers here: http://www.miklor.com/COM/UV_CHIRP.php

(Chirp compatible radios)

AnyTone

  • AT-5888UV
    Also includes the Intek HR-2040
    Also includes the Polmar DB-50M
    Also includes the Powerwerx DB-750

Alinco

  • DR-03T
  • DR-06T
  • DR135T
  • DR235T
  • DR435T
  • DJ596T
  • DJ175T

Baofeng/Pofung

  • F-11
  • UV-3R
  • UV-5R and variants
  • UV-6
  • UV-82/82L/82X
    Also includes the GT-5
  • UV-82C
  • UV-82HP/82DX/82HX
  • UV-B5/B6
    Also includes the BF-V85
  • BF-666S/777S/888S
    Also includes the GT-1
  • BF-F8HP
    Also includes the BF-A58
    Also includes the BF-F9V2+
    Also includes the GT-3TP
    Also includes the UV-5RTP
    Also includes the UV-5R7W

Baojie

  • BJ-UV55
  • BJ-9900

BTECH

  • UV-2501
  • UV-2501+220
  • UV-5001

Feidaxin

  • FD-150A
  • FD-160A
  • FD-268A
  • FD-268B
  • FD-288A
  • FD-288B
  • FD-450A
  • FD-460A

Icom

  • IC-80AD
  • IC-2820H
  • ID-800H
  • ID-880H
  • IC-208H
  • IC-2200H
  • IC-91/92AD
  • IC-V/U82
  • ID-RPx000V/RP2x
  • IC-2100H
  • IC-2720H
  • IC-T70
  • IC-T7H
  • IC-T8A
  • IC-Q7A
  • IC-W32A
  • IC-746
  • IC-7200
  • IC-7000
  • ID-31A
  • ID-51A

Intek

  • KT-980HP

Jetstream

  • JT220M
  • JT270M
  • JT2705M (use QYT KT-UV980)
Juentai

  • JT-6188 Mini (use QYT KT8900)

Kenwood

  • TH-D7A/G
  • TH-D72
  • TH-F6A
  • TH-F7E
  • TH-G71A
  • TH-K2
  • TK-260/270/272/278
  • TK-260G/270G/272G/278G
  • TK-360/370/372/378
  • TK-760/762/768
  • TK-760G/762G/768G
  • TK-860/862/868
  • TK-860G/862G/868G
  • TK-7102/8102/7108/8108
  • TM-271A
  • TM-281A
  • TM-D700
  • TM-D710
  • TM-G707
  • TM-V7A
  • TM-V71A

KYD

  • NC-630A

Leixen

  • VV-898

Puxing

  • PX-2R (UHF)
  • PX-777

QYT

  • KT-UV980
  • KT8900 (same as KT-8900)

Retevis

  • H-777 (use Baofeng BF-888)
  • RT-B6 (use Baofeng UV-B5)

Sainsonic

  • GT-890 (use QYT KT8900)

TYT

  • TH-UV3R
  • TH-UVF1
  • TH-9000
  • TH-9800

Yaesu

  • FT-1D
  • FT-50R
  • FT-60R
  • FT-90R
  • FT-817/ND
  • FT-857/D
  • FT-897
  • FT-1802M
  • FT-2800M
  • FT-1900R/2900M
  • FT-7800R/7900R
  • FT-8800R
  • FT-8900R
  • FTM-350R
  • VX-170
  • VX-2R
  • VX-3R
  • VX-5R
  • VX-6R
  • VX-7R
  • VX-8R

WACCOM

  • MINI-8900

Wouxun

  • KG-UVD1P/UV2D/UV3D
  • KG-UV6D/UV6X
  • KG-UV8D
Read More

Indy downtown lightning – July 13th, 2015

Read More
Baofeng UV-82 Indy 500 Frequencies for 2015
May21

Baofeng UV-82 Indy 500 Frequencies for 2015



PLEASE SEE THE UPDATED 2016 FREQ LIST HERE



CaptureI’ve used the CHIRP software to program my Baofeng UV-82 with all of the driver’s frequencies for the 2015 Indy 500. Each drive is input on the channel that corresponds with their car number- this way you can simply type in the car number and start listening. (With the UV-82, you have to enter three digits, so Car #1 – Will Power – is brought up by pressing 0-0-1 on the scanner)

Features:

  • name displayed on screen for selected car
  • local HAM calling frequency and repeaters set on channel 101 through 110.
  • transmitting has been disabled on UHF (same frequencies you are scanning)
  • officials on channels 122 and 123
  • PA system on 124 and 125
  • Race Control on 126
  • IMS Broadcast on 127
  • FM Radio set to 97.1 – FM IMS broadcast station
  • Channel 101-110, and 127 are set to be skipped while scanning

Download the CHIRP .csv export here: < < < DOWNLOAD > > >

Download the Baofeng UV-82 2015 Indy 500 CHIRP .img file here:
*******WARNING******** This is for the UV-82 ONLY — If you have a different radio, please download the CSV file above, and create your own. *******WARNING******** use at your own risk:< < <  DOWNLOAD  > > > *******WARNING********

I will update the file if I am made aware of changes and updates up until I leave for the track.
If you know of a change that should be made- email me.
If you have a similar file for another radio, you can email that file to me, and I’ll put it online here too.

I’ve also listed the frequencies below- if you want to do your own programming.

Car # Name Frequency
1 POWER 466.2125
2 MONTOYA 464.9250
3 CASTRON 464.5750
4 COLETTI 461.9375
5 HINCHCL 469.4375
7 JAKES 464.4625
8 SAAVEDR 461.1875
9 DIXON 461.6125
10 KANAAN 467.0375
11 BOURDAI 464.2500
14 SATO 467.0750
15 RAHAL 466.9125
18 HUERTAS 463.6000
19 DRACONE 467.2000
20 FILIPPI 469.1125
21 NEWGARD 469.9250
22 PAGENAU 464.1875
25 WILSON 468.4500
26 MUNOZ 467.4000
27 ANDRETT 469.1375
28 HUNTER- 469.3000
41 HAWKSWO 461.8375
83 KIMBALL 466.1875
98 CHAVES 462.2625
OFFICIA 464.1750
OFFICIA 468.8250
PA 450.1375
PA 455.1375
RCECTRL 468.8250
BROADCA 454.0000
Read More
